Hardware Compatiblity

hardware-compatibility

VT3 allows you to implement the devices COBO on web with maximum compatibility.

So it will be possible to build a complete and customizable machine System Structure.

The software also allows you to create graphic projects of COBO Display customized for the customer.

The following components are compatible with COBO VT3

CONTROLLERS	NAME	DESCRIPTION	DATASHEET
	MC²M	Double Core Multipurpose controller
	LE70	70 pins Multipurpose Controller for medium-large size machines
	LE56	56 pin multipurpose controller for medium-small size machines
	UAV2	Controller with integrated display and keypad
	MIDAC+ SERIES	35 pins Multipurpose Controller for small size machines
	"SMART IO" CONTROLLERS SERIES	Small machine sizes Master/Slave controllers
	POWER NODE CONTROLLERS SERIES	High power on/off modules
	POWER BRIDGE	High Power controller with PWM H-Bridge
	IO-CAB	Small size generic controller with high power outputs
	REC.ALL	Data logger recorder
	3B²	Remote GPS/GPRS and data logging system
	LIBERTY LINK	Control Unit Relay / CAN BUS Connection

CLUSTERS	NOME	DESCRIZIONE	DATASHEET
	GIGA	TFT display colour 3,5" QVGA LCD transflective Display 6 analog gauges 34 LED warning lights
	ECO MATRIX	LCD display 2 analog gauges with cross coil motor 21 LED warning lights
	AL-GA TFT	Colour 3.5" OVGA display 2 o 4 analog gauges
	AL-GA MATRIX EVO	LCD display Dot matrix 124x168 3 o 4 analog gauges

CLUSTERS

NOME

DESCRIZIONE

DATASHEET

GIGA

ECO MATRIX

AL-GA TFT

AL-GA MATRIX EVO

DISPLAYS 16 BIT	NAME	DESCRITPION	DATASHEET
	VIEW 2	QVGA Display (320x240) 5.7” LED technology Freescale Processor 16 bit FPGA graphic accelerator 16 keys keypad integrated Installation in landscape mode (horizontal) or portrait (vertical)
	CLS 2	Color Display 3.5" Freescale processor 16bit FPGA graphic accelerator 4 keys keypad integrated Installation even in very small cabins, thaks to its compact size
	CANVIEW 3	Display 3" (79x37 mm) do matrix transflective with LED backlighting If used as a primary display, will be possible with the aid on an external keyboard Can Bus If used as a secondary display, will be possible using the device in the touch-screen version
	CANVIEW 3 PLUS	Display 3" (79x37 mm) do matrix transflective with LED backlighting If used as a primary display, will be possible with the aid on an external keyboard Can Bus If used as a secondary display, will be possible using the device in the touch-screen version

DISPLAYS

16 BIT

NAME

DESCRITPION

DATASHEET

CLS 2

CANVIEW 3

Display 3" (79x37 mm) do matrix transflective with LED backlighting
If used as a primary display, will be possible with the aid on an external keyboard Can Bus
If used as a secondary display, will be possible using the device in the touch-screen version

CANVIEW 3 PLUS

Display 3" (79x37 mm) do matrix transflective with LED backlighting
If used as a primary display, will be possible with the aid on an external keyboard Can Bus
If used as a secondary display, will be possible using the device in the touch-screen version

DISPLAYS 32 BIT	NAME	DESCRIPTION	DATASHEET
	TERA 12	Display SVGA (800x600) 12” LED technology Processor ARM™ 32 bit Touch-screen glass-on-glass Scratchproof waterproof
	TERA 8	Display SVGA (800x600) 8” LED technology Processor ARM™ 32 bit Touch-screen glass-on-glass Scratchproof waterproof
	TERA 7	Display 7” (WVGA 800x480, 16;9) LED technology Processor ARM™ 32 bit 15 keys keypad integrated Touch-screen glass-on-glass opzional It is also provided with and additional I/O card
	TERA 7 FLEX	Display 7” (WVGA 800x480) LED technology Processor ARM™ 32 bit Horizontal or verticla installation Optional 5 key keyboard Glass-on-glass waterproof Scratchproof touch-screen optional
	TERA 12 HE	Display 1280x800 px, 12.1'' LED technology Processor Freescale iMx6 Dual Core, 32 bit Horizontal or vertical installation Full touch or 4+4 softkeys on front panel, 1 softkey programmable also as ON/OFF Capacitive multitouch with bonding technology (gloves compatible)
	CANVIEW 4	Display 480 x 272 px, 4.3'' LED technology ARM Cortex M4, 32 bit 5 softkeys on front panel
